Specifications
- Wavelengths: 1310 nm, 1490 nm, 1550 nm (±20 nm typical); up to 1625 nm optional
- Fiber Type: 9/125 µm SMF or 50/125 µm MMF
- Power Meter Range: −80 to +26 dBm (depending on model)
- Resolution: 0.01 dB
- Accuracy: ±0.2 dB (1310/1550 nm typical)
- Dynamic Range: 60–70 dB
- Output Power: Adjustable −7 to 0 dBm
- Modulation: CW, 270 Hz, 1 kHz, 2 kHz, Auto-λ
- Display: 128×64 dot backlit LCD (up to 3 results shown simultaneously)
- Interface: USB (Type A & B) for data, control, and host storage
- Power Supply: 4×AA batteries (> 100 h operation) or NiMH rechargeables
- Dimensions: 95 × 60 × 195 mm
- Weight: 0.5 kg
- Operating Temperature: −10 to +55 °C
