JDSU/VIAVI OFI FI-60

The FI-60 is a non-intrusive optical fiber identifier designed to detect active fiber traffic and signal direction without disconnecting or damaging the fiber. Ideal for use during maintenance or troubleshooting in live fiber networks, it supports detection of CW, 270 Hz, 1 kHz, and 2 kHz tones.

Rp 0.00 per Day

This combination does not exist.



SpecificationsPacking ListResources

Specifications

  • Fiber Types: 250 µm, 900 µm, 2 mm & 3 mm jacketed fiber
  • Wavelength Range: 800–1700 nm
  • Signal Detection: CW, 270 Hz, 1 kHz, 2 kHz modulated tones
  • Display: Backlit LCD with direction and power indication
  • Insertion Loss: <1 dB (typical)
  • Battery: Up to 80 hours (9V battery)
  • Features: Traffic direction indication, audible tone detection, clamp-style head for fast testing

Packing List

  1. Body JDSU/VIAVI OFI FI-60
  2. Softcase
  3. 2 Pcs Connector
  4. 1 Pcs Connector Shield
  5. USB Cable
  6. User Manual

Resources

Body JDSU/VIAVI OFI FI-60 Datasheet
