JDSU/VIAVI Ber Test Ethernet HST 3000 ETH

The JDSU HST-3000 Ethernet Service Interface Module (SIM) is a portable Gigabit Ethernet test solution designed for installation, service activation, and troubleshooting of access and carrier Ethernet networks. Supporting both optical and electrical Ethernet interfaces, the HST-3000 Ethernet SIM delivers multi-layer testing, ITU-T Y.1564 service activation, RFC 2544 performance validation, Carrier Ethernet OAM, and application-layer analysis in a single handheld platform.

Specifications

Interfaces: Optical Ethernet 100/1000 Mbps (dual SFP), Electrical Ethernet 10/100/1000 Mbps (dual RJ-45)
Service Activation & Performance: SAMComplete™ (ITU-T Y.1564), enhanced RFC 2544 (throughput, latency, frame loss, back-to-back, FDV/jitter)
Ethernet & IP Testing: Layer 2–4 traffic generation, multi-stream testing (up to 8 streams), IPv4/IPv6, VLAN, Q-in-Q, MPLS, PBB
OAM & QoS Validation: IEEE 802.1ag and ITU-T Y.1731 Ethernet OAM, SLA and KPI verification (CIR, EIR, FD, FDV, FLR)
Troubleshooting Tools: Line-rate traffic analysis, dual-port Thru/Monitor mode, advanced filtering and protocol monitoring
Application Testing: VoIP service testing (MOS, R-Factor), IP video / multicast analysis, HTTP/FTP and TCP/UDP performance
Fiber Support (Optional): USB P5000i fiber inspection and optical power measurement support
Platform: Modular HST-3000 handheld test set for field installation and maintenance

Packing List

Body HST3000-SIM + Battery Pack
AC Adapter 12V 3,5A
Cable UTP RJ45 CAT6 3M
Softcase
CD Manual/USB Flashdisk

Resources

JDSU/VIAVI Ber Test Ethernet HST 3000 ETH Datasheet
