Specifications
- Primary Application: Portable RF spectrum and interference analysis
- Frequency Range: Up to 9 / 13 / 20 GHz (depending on hardware configuration)
- Dynamic Range: >106 dB (typical)
- DANL: Up to –164 dBm (1 Hz RBW)
- Measurements: Channel Power, Occupied Bandwidth, ACPR, C/I
- Detectors: Peak, RMS, Sample, Quasi-peak
- Markers: Up to 6 markers with delta functions
- Display: Color touchscreen with graphical interface
- Sweep Speed: Fast sweep mode with Burst Detect™
- Battery Operation: Approx. 3 hours typical
- Connectivity: USB and Ethernet data transfer
- Design: Compact rugged handheld platform
Installed Options
Option 25 – Interference Analyzer
Spectrogram and RSSI monitoring
Signal ID and long-duration interference logging
Interference mapping support
Signal strength audio/visual indication
Option 31 – GPS Receiver
GPS tagging for saved traces
High frequency accuracy with GPS lock
Location, time, and altitude logging
Option 720 – Tracking Generator
Built-in tracking generator functionality
Supports cable, filter, and component frequency response testing
Enables scalar transmission measurements
