Specifications
- Data Rate: 4 × 25.78125 Gbps (aggregate 100 Gbps)
- Transmission Distance: Up to 70 m (OM3) / 100 m (OM4)
- Wavelength: 850 nm (VCSEL)
- Form Factor: QSFP28, hot-pluggable
- Connector: MPO 12-fiber
- Average Output Power (per lane): – to +2.4 dBm
- Receiver Sensitivity (OMA, per lane): ≤ –5.2 dBm
- Power Consumption: < 2.5 W
- Operating Temp: 0°C to 70°C
- Digital Diagnostics: Supported (DDM)
- Compliant Standards: IEEE 802.3bm 100GBASE-SR4, RoHS 6, Class 1 Laser
Applications:
- 100GBASE-SR4 Ethernet links
- High-speed server-to-switch interconnects
- Data center aggregation and core switch uplinks
