Specifications
- Primary Application: 100G long-haul optical transmission
- Standard Compliance: 100GBASE-ZR, QSFP28 MSA compliant
- Data Rate: 103.125 Gb/s aggregate
- Architecture: 4 × 25G LAN-WDM lanes
- Optical Interface: Duplex LC connector
- Transmission Distance: Up to 80 km over G.652 SMF
- Wavelength (LAN-WDM): ~1295 nm – 1310 nm (4 lanes)
- Electrical Interface: 4 × 25G
- Power Supply: Single +3.3V
- Power Consumption: ≤ 6.5 W
- Receiver Sensitivity: Down to ~ –28 dBm
Operating Temperature:
- Commercial: 0 to +70°C
- Extended: –10 to +80°C
- Industrial: –40 to +85°C
- Form Factor: QSFP28, hot-pluggable
- Compliance: RoHS-10, lead-free
