MTNetworks SFP 1.25G LR 1310nm 10km Duplex LC SMF Transceiver Module

The MTNetworks MT-SFP-LR is a high-performance and cost-effective 1.25 Gbps SFP optical transceiver designed for long-distance data transmission over single-mode fiber. Operating at 1310 nm wavelength, this module supports up to 10 km reach, making it suitable for Gigabit Ethernet, fiber channel, and general optical communication systems.

With hot-pluggable capability, low power consumption, and full compliance with SFP MSA and IEEE standards, the MT-SFP-LR ensures stable and reliable performance for network deployments in enterprise, ISP, and data communication environments.

Rp 0.00 Rp 0.00

Specifications


  • Primary Application: 1G optical transmission (Gigabit Ethernet / Fiber Channel)
  • Data Rate: Up to 1.25 Gbps
  • Transmission Distance: Up to 10 km over single-mode fiber
  • Wavelength: 1310 nm (FP laser)
  • Optical Interface: Duplex LC connector
  • Standards Compliance: IEEE 802.3z (1000BASE-LX), SFP MSA, SFF-8472
  • Output Power: –9 to –3 dBm
  • Receiver Sensitivity: Up to –20 dBm
  • Extinction Ratio: ≥ 9 dB
  • Bit Error Rate: ≤ 1 × 10⁻¹²
  • Power Supply: +3.3 V
  • Power Consumption: ≤ 1 W
  • Interface: LVPECL compatible I/O
  • Diagnostics: Digital Diagnostic Monitoring (DDM) via SFF-8472
  • Operating Temperature: –5°C to +70°C
  • Storage Temperature: –40°C to +85°C
  • Humidity: 5% – 95%
  • Form Factor: SFP, hot-pluggable
  • Compliance: RoHS-6, Class 1 Laser Safety
