Specifications
- Primary Application: Gigabit Ethernet, 1G Fibre Channel, Optical Transmission Systems, and Long-Haul Backbone Networks.
- Supported Standards: SFP MSA and SFF-8472 with Digital Diagnostic Monitoring (DDM).
- Data Rate: 100 Mbps to 1.25 Gbps.
- Transmission Distance: Up to 160 km over Single-Mode Fiber (SMF).
- Transmit Wavelength: 1550 nm.
- Receive Wavelength: 1260–1610 nm.
- Optical Interface: Duplex LC connector.
- Optical Technology: 1550 nm DFB laser transmitter with Super TIA + APD photodiode receiver.
- Average Transmit Power: +1 to +5 dBm.
- Receiver Sensitivity: ≤ −32 dBm.
- Receiver Overload: −8 dBm.
- Extinction Ratio: ≥ 9.0 dB.
- Optical Budget: Approximately 33 dB (Tx Min +1 dBm, Rx Sensitivity −32 dBm).
- Form Factor: Hot-pluggable SFP.
- Digital Diagnostics: Real-Time Digital Diagnostic Monitoring (DDM) supporting temperature, supply voltage, laser bias current, transmit optical power, and receive optical power.
- Power Supply: Single +3.3 V.
- Power Consumption: ≤ 1.0 W (300 mA maximum @ 3.3 V).
Operating Temperature:
- Standard: 0°C to +70°C
- Extended: −20°C to +80°C
- Industrial: −40°C to +85°C.
- Compliance: SFP MSA, SFF-8472, Class 1 Laser Product, and RoHS compliant.
