Specifications
- Primary Application: 25G Ethernet, Enterprise Networks, Carrier Networks, Mobile Fronthaul, and Data Center Interconnect (DCI)
- Supported Standard: 25GBASE-LR, SFP28 MSA, SFF-8472
- Data Rate: Up to 25.78 Gbps
- Transmission Distance: Up to 20 km over single-mode fiber (SMF)
- Wavelength: Type A: Tx1270 nm / Rx1330 nm • Type B: Tx1330 nm / Rx1270 nm
- Optical Interface: Simplex LC connector
- Optical Technology: DFB transmitter with PIN photodiode receiver (TIA integrated)
- Form Factor: SFP28, hot-pluggable
- Digital Diagnostics: Built-in Real-Time Digital Diagnostic Monitoring (DDM)
- Power Consumption: ≤ 1.32 W (400 mA @ 3.3 V typical)
- Power Supply: Single +3.3 V
- Operating Temperature: 0°C to +70°C
- Compliance: SFP28 MSA, SFF-8472, RoHS compliant
