Specifications
- Data Rate: 9.95 to 11.1 Gbps (10G Ethernet, SONET OC-192, SDH STM-64, 10G Fibre Channel)
- Transmission Distance: up to 80 km
- Wavelength: C-band (1528–1564 nm)
- Transmitter: Cooled EML laser, Output Power 0 to +4 dBm, Extinction Ratio ≥ 8.2 dB
- Receiver: APD photodiode, Sensitivity -24 dBm (9.95G), -23 dBm (10.7G), Overload -7 dBm
- Power Dissipation: ≤ 3.5 W
- Operating Temperature: -5°C to +70°C (Case)
- Digital Diagnostics Monitoring (DDM): temperature, supply voltages, bias current, Tx/Rx optical power
- Compliance: RoHS, Class 1 laser safety
Applications:
- SONET OC-192 / SDH STM-64
- 10G Ethernet (LAN/WAN)
- 10G Fibre Channel (80 km)
Ordering Informations
Part Number | Product Description |
MT-XFP-ZR L-64.2ax | 10Gbps, XFP 80km, -5ºC ~ +70ºC |
