Specifications
- Data Rate: 2.488 Gbps
- Reach: Up to 40 km over SMF
- Wavelengths: CWDM 1270–1610 nm
- Transmitter: DFB laser
- Receiver: PIN photodiode
- Average Output Power: 0 to +5 dBm
- Receiver Sensitivity: ≤ –24 dBm
- Connector: LC Duplex, hot-pluggable
- Digital Diagnostics (DDM): Supported
- Operating Temp: 0°C to +70°C
- Compliance: SFP MSA, SFF-8472, RoHS
Applications:
- SDH STM-16 / SONET OC-48
- 2X Fibre Channel
- Switch-to-switch interconnect
- Switched backplane systems
- Router/server uplinks
- Other CWDM optical transport systems
Ordering Informations
| Part Number | Product Description |
| MT-SFP-ER1270 | Single mode dual fiber, 2.5G,40km, CWDM 1270nm, LC interface |
| MT-SFP-ER1290 | Single mode dual fiber, 2.5G,40km, CWDM 1290nm, LC interface |
| MT-SFP-ER1310 | Single mode dual fiber, 2.5G,40km, CWDM 1310nm, LC interface |
| MT-SFP-ER1330 | Single mode dual fiber, 2.5G,40km, CWDM 1330nm, LC interface |
| MT-SFP-ER1350 | Single mode dual fiber, 2.5G,40km, CWDM 1350nm, LC interface |
| MT-SFP-ER1370 | Single mode dual fiber, 2.5G,40km, CWDM 1370nm, LC interface |
| MT-SFP-ER1390 | Single mode dual fiber, 2.5G,40km, CWDM 1390nm, LC interface |
| MT-SFP-ER1410 | Single mode dual fiber, 2.5G,40km, CWDM 1410nm, LC interface |
| MT-SFP-ER1430 | Single mode dual fiber, 2.5G,40km, CWDM 1430nm, LC interface |
| MT-SFP-ER1450 | Single mode dual fiber, 2.5G,40km, CWDM 1450nm, LC interface |
| MT-SFP-ER1470 | Single mode dual fiber, 2.5G,40km, CWDM 1470nm, LC interface |
| MT-SFP-ER1490 | Single mode dual fiber, 2.5G,40km, CWDM 1490nm, LC interface |
| MT-SFP-ER1510 | Single mode dual fiber, 2.5G,40km, CWDM 1510nm, LC interface |
| MT-SFP-ER1530 | Single mode dual fiber, 2.5G,40km, CWDM 1530nm, LC interface |
| MT-SFP-ER1550 | Single mode dual fiber, 2.5G,40km, CWDM 1550nm, LC interface |
| MT-SFP-ER1570 | Single mode dual fiber, 2.5G,40km, CWDM 1570nm, LC interface |
| MT-SFP-ER1590 | Single mode dual fiber, 2.5G,40km, CWDM 1590nm, LC interface |
| MT-SFP-ER1610 | Single mode dual fiber, 2.5G,40km, CWDM 1610nm, LC interface |
