MTNetworks SFP28 25G ER CWDM 40km

MTNetworks SFP28 25G ER CWDM 40km

The MT-SFP25G-ERxxxx is a high-performance 25G CWDM SFP28 optical transceiver designed for up to 40 km SMF transmission. Featuring an integrated cooled DML laser and high-sensitivity APD receiver, it ensures excellent performance in long-haul CWDM applications.
Rp 0.00 Rp 0.00
Rp 1.00

  • Wavelenght (λ)

This combination does not exist.



SpecificationsOrdering InformationsResources

Specifications

  • Data Rate: Up to 25.78 Gbps
  • Reach: Up to 40 km over SMF
  • Wavelengths: CWDM 1270–1370 nm
  • Transmitter: Cooled DML laser
  • Receiver: APD with TIA
  • Average Output Power: –2 to +6 dBm
  • Receiver Sensitivity: ≤ –19 dBm
  • Connector: LC Duplex, hot-pluggable
  • Digital Diagnostics (DDM): Supported
  • Operating Temp: 0°C to +70°C
  • Compliance: SFP28 MSA, SFF-8431/8432, RoHS

Applications:

  • 25G Ethernet
  • eCPRI / CPRI Option 10 (5G fronthaul)
  • CWDM long-distance transport
  • Data center and carrier optical backbone


Ordering Informations

Part Number Product Description
MT-SFP25G-ER1270 Single mode dual fiber, 25G,40km, CWDM 1270nm, LC interface
MT-SFP25G-ER1290 Single mode dual fiber, 25G,40km, CWDM 1290nm, LC interface
MT-SFP25G-ER1310 Single mode dual fiber, 25G,40km, CWDM 1310nm, LC interface
MT-SFP25G-ER1330 Single mode dual fiber, 25G,40km, CWDM 1330nm, LC interface
MT-SFP25G-ER1350 Single mode dual fiber, 25G,40km, CWDM 1350nm, LC interface
MT-SFP25G-ER1370 Single mode dual fiber, 25G,40km, CWDM 1370nm, LC interface


Resources

 MTNetworks SFP28 25G ER CWDM 40km Datasheet
