MTNetworks SFP+ 10G LR 1310nm 20km

Name: MTNetworks SFP+ 10G LR 1310nm 20km
Availability: InStock

The MT-SFP+-LR is a high-performance 10Gbps SFP+ optical transceiver designed for long-reach Ethernet applications over single-mode fiber (SMF). Compliant with 10GBASE-LR/LW, SFP+ MSA, and SFF-8431/8472, this module delivers reliable connectivity up to 20 km with low power consumption and full digital diagnostics support.

This combination does not exist.

Specifications

Data rate up to 11.1 Gbps
Transmission distance: Up to 20 km over 9/125 μm SMF
Wavelength: 1310 nm DFB laser
Optical Output Power: –6 to –1 dBm
Receiver Sensitivity: ≤ –14.4 dBm
Compliant with SFP+ MSA, IEEE 802.3ae, SFF-8431/8472
Hot-pluggable with LC duplex interface
Integrated Digital Diagnostic Monitoring (DDM)
Power dissipation: <1.5 W
Operating temperature: 0°C to 70°C
Metal housing for enhanced EMI shielding
RoHS compliant, Class 1 laser product

Applications:

10GBASE-LR/LW Ethernet
High-speed interconnects in metro/access networks
Data center uplinks and switch interconnections

Ordering Informations

Part Number	Product Description
MT-SFP+-LR	10Gb/s 1310nm SFP+ 20km Transceiver

Resources

MTNetworks SFP+ 10G LR Datasheet
