Specifications
- Automatic fiber end-face inspection and certification with instant Pass/Fail analysis
- Dual magnification (200X and 400X) for both overview and detailed inspection
- USB 2.0 connectivity (compatible with laptops, PCs, and VIAVI test devices)
- Compatible with FiberChekPRO™ and FiberChekMOBILE software for analysis and reporting
- Automatic image centering ensures perfect alignment on screen
- Supports over 300 tip adapters for all major connector types
- High-resolution CMOS sensor: 2560 × 1920 pixels
- Detection capability: particles smaller than 1 μm
- Light source: Blue LED (100,000+ hours lifetime)
- Live image: 640 × 480 pixels @ 8 fps
- Power source: USB port (no external power required)
- Operating temperature: 0°C to +40°C
- Weight: 110 g
- Dimensions: 140 × 46 × 44 mm
Optional Wireless Adapter (FBPP-WIFI)
- Enables wireless use with Android, iOS, and Windows devices
- Internal Li-ion battery, 5.5 hours runtime
- USB charging (5VDC, 2.1A adapter)
