Specifications
- Supports cladding diameters 125–680 μm, coating diameters 210–900 μm
-
Accurate core-to-core alignment with low splice loss:
– SM (G.652): 0.03 dB
– MM (G.651): 0.02 dB
– DS (G.653): 0.05 dB - Return loss >60 dB
- Typical splice time: 35 s (400 μm cladding fiber)
- Typical heating time: ~26 s (customizable)
- Fiber magnification: 100–200× adjustable
- Display: 5” HD color LCD, dual high-sensitivity camera
- Splicing modes: 40, with manual/auto splicing & heating
- Data storage: 10,000 fusion records + 100 images
- Interfaces: USB 2.0, RS232, customizable output signal
- Electrode life: up to 3000 arcs (125 μm fiber), 1000 arcs (250 μm fiber)
- Ruggedized housing: water-resistant, dustproof, shockproof
- Dimensions/Weight: 330 × 220 × 170 mm / 7.29 kg
- Power Supply: AC 100–240 V input / DC 11–13.5 V, 10 A output
Applications:
- Large Diameter Fiber (LDF) splicing
- EDF, DCF, and other specialty fibers
- Telecom and optical component manufacturing
- Research and industrial fiber optic projects
Packing List
- LDF Fusion Splicer
- Fiber Stripper
- Fiber Holders
- Spare Electrodes
- User Manual(USB drive)
- Power Adapter
- Power Cord
- Carrying Case
