Specifications
- Small, light, and portable design
- One-click red light (VFL) switch-on function (X-30B)
- 3.5” TFT LCD touch screen + keypad
- Rugged casing: dustproof & shockproof
- Auto sleep mode for power saving
- USB & SD card data exchange, fast PC analysis & reporting
- Large-capacity Li-battery, ≥10 h continuous operation
- Storage capacity: >60,000 traces
- Event dead zone: 1.8 m, Attenuation dead zone: 10 m
- Distance range: 0.3–120 km
-
Dynamic range:
– X-30A: 30/28 dB @1310/1550 nm
– X-30B: 32/30 dB @1310/1550 nm, with VFL 650 nm (3 km) - Pulse width: 5–20,480 ns + Auto mode
- Interfaces: USB, SD card
- Optical port: FC/UPC (FC/SC optional, UPC/APC available)
- Dimensions/Weight: 220 × 106 × 60 mm / 0.88 kg
- Operating temperature: –10°C to +50°C
Applications:
- FTTx testing & troubleshooting
- CATV network maintenance
- Metropolitan Area Networks (MAN)
- Wide Area Networks (WAN)
- General fiber construction & monitoring
Packing List
- OTDR main unit
- Carrying pocket
- Power adapter & cord
- Strap
- User manual
