SHINHO X-5007 Visual Fault Locator (VFL)

SHINHO X-5007 Visual Fault Locator (VFL)

The SHINHO X-5007 is a rugged and portable Visual Fault Locator designed for quick and reliable fiber troubleshooting. Built with a durable metal case and ESD protection, it ensures long service life and stable performance in the field. With multiple output power options and long battery life, it is an essential tool for optical network maintenance.
Rp 0.00 Rp 0.00
Rp 0.00

This combination does not exist.

Packing LisSpecifications

Specifications

  • Wavelength: 650 nm ± 10 nm (635 nm optional)
  • Output Power Options: 1 mW, 10 mW, 20 mW, 30 mW, 50 mW
  • Emitter Type: FP-LD laser diode
  • Connector: 2.5 mm universal (optional FC male to LC female adapter for 1.25 mm)
  • Operation Modes: CW and 2–3 Hz Pulse
  • Durability: Metal housing, integrated design, replaceable ceramic tube
  • Battery Life:
    – ≥ 65 hrs @ 1 mW
    – ≥ 15 hrs @ 10 mW
  • Power Supply: 2 × AA alkaline batteries
  • Operating Temp: –10°C ~ +45°C; Storage: –40°C ~ +70°C
  • Size/Weight: Ø15 × 210 mm / 120 g (without battery)
  • Other Features: Low battery indication, long operating life, ESD protection for LD

Applications:

  • Optical fiber break and fault location
  • Continuity and end-to-end verification
  • Live fiber identification for FTTx, CATV, and telecom

Packing List

  1. X-5007 Visual Fault Locator
  2. User manual
  3. Soft carrying case
  4. 2 × AA batteries
