Shinho Fiber Optic Light Source (OLS) X-0512

Specifications

• Compact, lightweight design with good output power stability
• Large LCD display with backlight and battery status indicator
• Optional auto-shutdown function for energy saving
• Supports single, dual, or tri-wavelength operation
• Emitter type: FP-LD
• Available wavelengths: 850, 1300, 1310, 1490, 1550, 1625 nm (1–3 selectable)
• Optical connector: FC (SC/ST optional)
• Output power:
  • ≥ 3 mW @ 650 nm
  • ≥ –7 dBm @ 850/1300 nm
  • ≥ –7/0 dBm @ 1310/1490/1550/1625 nm
• Output stability: ±0.04 dB (15 min @ 20 °C)
• Modulation frequencies: CW, 2 Hz @ 650 nm; CW, 270 Hz, 1 kHz, 2 kHz @ other wavelengths
• Applicable fiber: SM and MM
• Power supply: 3 × AAA (1.5 V) batteries, working time up to 40 hours
• Operating temperature: –10 °C ~ +50 °C
• Storage temperature: –20 °C ~ +70 °C
• Dimensions / Weight: 125 × 65 × 29 mm / 160 g

Applications

• Telecommunication maintenance
• CATV maintenance
• Optical fiber laboratories
• Fiber optic sensing systems
