Specifications
- Simultaneous measurement at 1310 nm, 1490 nm, 1550 nm for EPON/GPON/GEPON
- Supports 1310 nm burst mode upstream testing
- Threshold setting available directly on the tester (up to 10 sets)
- USB port for PC data transfer & user self-calibration
- Auto-off function (10 min) – user selectable
- High measurement accuracy with low insertion loss (<1.5 dB)
- Compact and lightweight design for field applications
- Wavelengths: 1310 nm / 1490 nm / 1550 nm
- Pass Zones: 1260–1360 nm / 1470–1505 nm / 1535–1570 nm
- Isolation: >40 dB (1490/1550), >30 dB (1310)
-
Measurement Range:
– 1310 nm: –40 ~ +10 dBm
– 1490 nm: –40 ~ +10 dBm
– 1550 nm: –40 ~ +20 dBm - Accuracy: ±0.5 dB (uncertainty), ±0.1 dB (linearity)
- Insertion Loss: <1.5 dB
- Detector Type: InGaAs
- Optical Connector: FC/SC interchangeable
- Fiber Type: 9/125 µm
- Display: LCD 128 × 64
- Units: dB, dBm, xW
- Resolution: 0.01 dB
- Power Supply: 3 × AA 1.5V batteries
- Operating Temp: –10°C ~ +60°C
- Storage Temp: –25°C ~ +70°C
- Dimensions/Weight: 200 × 90 × 50 mm / 285 g
Applications:
- FTTx installation & maintenance
- EPON/GPON/GEPON testing
- Triple-play (voice, video, data) signal verification
Packing List
- PON power meter
- Manual
- Soft carrying case
- 1.5V AA batteries
- Cotton swabs
