Shinho Fiber Cleaver X-55B

Name: Shinho Fiber Cleaver X-55B
Availability: InStock

The SHINHO X-55B is a robust, high-precision fiber cleaver designed for single-core fibers, featuring automatic blade rotation that changes the cleaving blade position after every cut. This ensures consistent performance, extends blade life, and significantly improves efficiency. With its one-step cleaving and scrap collection system, the X-55B is ideal for telecom, CATV, and fiber optic installation projects.

This combination does not exist.

Specifications

Supports 125 μm bare fibers, coating diameters 0.25–0.9 mm
Designed for single-core optical fibers
Cleave length: 5–16 mm
Typical cleave angle: ≤0.5°
Automatic mode: blade rotates after each cleave
Long blade life: up to 60,000 cleaves
One-step operation including scrap collection
Compact and lightweight: 103 × 93 × 47 mm / 340 g
Package includes:

Applications:

Fiber preparation for fusion splicing
Telecom and CATV installation & maintenance
Optical lab and field applications

Packing List

Fiber cleaver
user manual
carrying case
screwdriver
