Shinho Fiber Fusion Splicer X-600

Specifications

• Applicable Fibers: SM (G.652), MM (G.651), DS (G.653), NZDS (G.655)
• Cladding Diameter: 80–150 μm
• Coating Diameter: 160–3000 μm
• Cleaved Length: 5–16 mm (<250 μm coating), 16 mm (250–1000 μm coating)
• Typical Splice Loss: SM: 0.02 dB, MM: 0.01 dB, DS/NZDS: 0.04 dB
• Return Loss: >60 dB
• Splicing Programs: 80 groups, manual/automatic modes
• Fiber Magnification: 320× (X or Y view), 160× (X and Y view)
• Display: Dual camera, 4.3" 800×480 LCD (touch optional)
• Data Storage: 8000 splice records
• Battery: 5200 mAh, up to 250 splice/heat cycles per charge
• Electrode Life: >5000 ARC discharges
• Operating Conditions: –10°C to +50°C, up to 5000 m altitude, ≤15 m/s wind
• Dimensions/Weight: 200×123×95 mm / 1.66 kg (with battery)

Applications:

• FTTx / FTTH deployments
• CATV network installations
• Long-distance optical network projects

Packing List

1. Fusion Splicer X-600
2. Fiber Cleaver
3. Fiber Stripper
4. Cooling Tray
5. Spare Electrodes
6. Stripper
7. Carrying Box
8. Power Adapter
9. Power Plug
10. User Manual
11. Strap
12. Cleaning Brush

Resources

Shinho Fiber Fusion Splicer X-600 Datasheet
