Shinho Ribbon Thermal Stripper X-18

The SHINHO X-18 is a handheld thermal stripper designed for non-destructive stripping of ribbon fiber jackets (up to 12 fibers). With fast heating, adjustable temperature levels, and ergonomic design, it ensures efficient and reliable fiber preparation for splicing, whether in the lab or field. Its compact and rugged body makes it suitable for demanding environments.
Rp 0.00 Rp 0.00
Rp 13,188,000.00

This combination does not exist.

SpecificationsPacking List

Specifications

  • Supports single fiber and ribbon fiber (up to 12 cores)
  • Fast heating: ~10 s (normal mode), with 4 selectable temperature levels (60°C, 80°C, 100°C, 120°C)
  • Maximum stripping length: 30 mm
  • Coating material: UV-curable resin; cladding diameter: 125 μm
  • Compatible holders: FH-2, FH-4, FH-6, FH-8, FH-10, FH-12
  • Battery: 2000 mAh Li-ion, ~600 cycles per charge (3 h full charge)
  • Heating modes: Normal and Eco
  • Compact and lightweight: 155 × 50 × 40 mm, 267 g (with battery)
  • Power supply: AC 100–240 V input / DC 12 V 1 A output
  • Rugged, durable design; CE and RoHS compliant

Applications:

  • Ribbon fiber splicing preparation (up to 12 cores)
  • Single fiber stripping for telecom and CATV projects
  • Optical component manufacturing and R&D
  • Field and laboratory use requiring compact tools

Packing List

  1. Thermal stripper
  2. AC adapter
  3. Cleaning brush
  4. Carrying case
